Key Characteristics :

Capacities:

Metal Construction: up to 17,600 gpm (4,000 m3/hr)

Elastomer Construction: up to 6,385 gpm (1,450 m3/hr)

 Heads:

Metal Construction: up to 312 ft (95m)

Elastomer Construction: up to 180 ft (55m)

Max Working Pressure:

Metal Construction: up to 232 psi (16 bar)

Elastomer Construction: up to 203 psi (14 bar)

Max Temperature:

230°F (110°C)

Discharge Sizes:

Metal Construction: From 2″ (50.8 mm) to 12″ (304 mm)

Elastomer Construction: From 2″ (50.8 mm) to 8″ (203 mm)

Main Benefits

Waterless Sealing Technology

 Leak less seal operation

 High durability

 High Chrome and elastomer lined constructions

 High Efficiency, low energy consumption

 Design for up to class 4 slurry services

 Heavy-Duty bearing offer LB10 bearing life of more than 50,000 hours

Main Applications

 Mining and mineral processing

 Aggregates (sand and gravel)

 Lime Slurry

 Food Industry

 Wastewater

 Chemical slurries
